    63Hz 15Watt Poe Power Supply , IEC60950-1 Desktop Power Supply

    Ask Lasest Price
    Brand Name : Stron
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 2000 set per month
    Delivery Time : 14 work days
    • Product Details
    • Company Profile

    63Hz 15Watt Poe Power Supply , IEC60950-1 Desktop Power Supply

    15Watt Desktop POE Power Supply 1000M + (4,5)pins; - (7,8) pins Electricity Supply


    ■Features :

    ·Universal AC input / Full range

    ·1000M Ethernet ports support

    ·+(4,5)pins; -(7,8)pins

    ·Forced the power into Ethernet ports

    ·Protections: Short circuit / Overload / Surge

    ·100% full load burn-in test

    ·No load consumption<0.1W@230VAC

    ·3 years warranty

    SPECIFICATION

    MODEL PGOB15D01-240060 PGOB15D01-500030 PGOB15D01-560027
    OUTPUT DC VOLTAGE 24V  50V  56V
    RATED CURRENT 0.6A  0.3A  0.27A
    RATED POWER 14.4W 15W 15.12W
    RIPPLE & NOISE (max.) 200mVp-p  200mVp-p  200mVp-p
    VOLTAGE TOLERANCE ±5%  ±5%  ±5%
    INPUT VOLTAGE RANGE 90~264Vac
    FREQUENCY RANGE 47~63Hz
    EFFICIENCY (Typ.) 83.92%(Meet DOE Ⅵ) 84.13%(Meet DOE Ⅵ) 84.17%(Meet DOE Ⅵ)
    AC CURRENT (Typ.) 0.35A max @100~240Vac
    INRUSH CURRENT (Typ.) COLD START 40A/100Vac 60A/240Vac
    PROTECTION OVERLOAD 120~200% rated output power
    Protection type : Hiccup mode, recovers automatically after fault condition is removed
    Short circuit Protection type : Hiccup mode, recovers automatically after fault condition is removed
    Lightning Surge L-N 6KV ; L&N-PE 6KV
    ENVIRONMENT WORKING TEMP. 0℃~40℃
    WORKING HUMIDITY 20%~95% RH non-condensing
    STORAGE TEMP., HUMIDITY -20℃~70℃ , 20%~95% RH
    VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
    SAFETY & EMC SAFETY STANDARDS UL60950-1, CB(IEC60950-1)
    EMI CONDUCTION & RADIATION EN55022, EN55024, FCC Part 15 Class B, GB9254, GB17625.1ect.
    OTHERS MTBF 50000hrs min. MIL-HDBK-217F(40℃)
